ROG Strix Helios GX601 Black

ROG Strix Helios

Case Size

Mid Tower

Motherboard Support

EATX (12"x10.9")

ATX

Micro-ATX

Mini-ITX

Drive Bays

4 x 2.5" Bay

2 x 2.5"/3.5" Combo Bay

Expansion Slots

8

2 (additional vertical)

Front I/O Port

1 x Headphone

1 x Microphone

4 x USB 3.1 Gen1

1 x USB 3.1 Gen2 Type C

LED Control Button

Fan Control Button

Reset Button

Tempered Glass

Front Side

Left Side

Right Side

Radiator Support (Front)

120 mm

140 mm

240 mm

280 mm

360 mm

420 mm

Radiator Support (Top)

120 mm

140 mm

240 mm

280 mm

360 mm

Radiator Support (Rear)

120 mm

140 mm

Cooling Support (Front)

3 x 120 mm

3 x 140 mm

Radiator + Fan Thickness: Max. 90 mm

Cooling Support (Top)

3 x 120 mm

2 x 140 mm

Radiator + Fan Thickness: Max. 60 mm

Cooling Support (Rear)

1 x 120 mm

1 x 140 mm

Pre-installed Fans (Front)

3 x 140 mm

Pre-installed Fans (Rear)

1 x 140 mm

Maximum CPU Cooler Height

190 mm

Maximum GPU Length

450 mm (Riser Cable above 200mm in length is required for one GPU install in vertical position)

Maximum PSU Length

220 mm

Removable Dust Filters

Front

Top

Bottom

Maximum Cable Management Space

33 mm

Dimensions

250 x 565 x 591 mm
